Description of 500-30000 Liters per hour water UF ultrafiltration machine:
Ultrafiltration (we called UF) is the most widely used membrane separation technology. It is mainly used for separation of substances at high molecular level. It has a very good effect on deeply reducing turbidity, clarification, sterilization and separation, concentration, classification and purification of macromolecular substances. In the field of water treatment, it can be used to remove suspended solids, particles, bacteria, virus, pyrogen and macromolecular organic substances in water and make water purified.
UF membrane is the key part of whole UF water purifier, it will decide the system workable or not. The water passing uf machine can remove bacterial, organic substance and microorganism.
Whole SUS304 rack, automation part apply AC contactor control, apply flow meter, pressure gauge and auto flush electrical magnetic valve, etc.
Protect device of Water filtration system: Low pressure and high pressure protect switch is set before water entry and after water discharge. Booster pump and system will stop when water supply is not enough. Make cut off on booster pump when there is too much discharge pressure to avoid system running under pressure exceeding status.
Flow chart of ultrafiltration machine:
Raw water tank→ raw water pump→ quartz sand filter→ active carbon filter→ water softner (optional) → security filter→ UF System (including chemical cleaning device)→ UV sterilizer (ozone generator)→ Pure water storage tank
Main Features of ultrafiltration machine:
1.UF filtration Can run and produce water continuously, highly automatic
2.No need chemical to regeneration,easy operation and maintaince
3.Automatic switch on when lack of water,and switch off when no water or full of water
4.UF membrane auto wash and reduce the pollution speed.
5.Low-pressure switch protects high-pressure pump from damage cause by water supply stops.
6.Production water conductivity meter monitors water quality online continuously.
7.Input water and dense water pressure meters.
Optional Components of ultrafiltration machine:
A. Regulating wheels
B. PLC Touch Screen
C. Two-stage RO system
D. PH adjustment anti-scale
E. Automatic cleaning system
F. Auto or manual control valve
G. U-PVC or stainless steel pipe
H. UV sterilizer/Ozone Generator
I. Dosing system/Water Softener
J. PE or stainless steel raw/pure water tank
K. FRP or stainless steel pre-treatment tank
